Durable COB Character LCD Displays for Industrial Applications

We manufacture reliable COB character LCD displays, including standard 16x2 LCD models and custom sizes, featuring crisp alphanumeric LCD readability with high contrast and wide viewing angles. Our character LCD displays use chip-on-board technology for rugged performance in industrial, medical, and commercial applications. Customizable with special symbols, multiple backlight colors, and wide temperature operation (-30°C to +80°C).

Character 16x1 LCD Module
Character 16x1 LCD Module
Character 16x1 LCD Module

Character 16x1 LCD Module

  • Manufacturer: SINDA
  • Product Name: 16x1 Character LCD Module Series | 16x1 Character Display
  • Backlight: White

16x1 character Liquid Crystal Display shows characters with white pixels on a blue background when powered on. This transmissive LCD Display requires a backlight for visibility while offering a wide operating temperature range from -20 to 70 degrees Celsius. This display has an optimal view of 6:00/12:00. This display operates at 3.3V/5V supply voltage and is RoHS compliant. For any other custom requests, feel free to contact us.

Inquire now back

ATTRIBUTES


Manufacturer

SINDA

Part Number

SDCB1601-01

Display Format

16x1  Character

Interface

6800 4-bit /  8-bit Parallel

IC or Equivalent

ST7066U  AIP31066  HD44780

Connection

Pin Header

Outline Dimension

80.00(W)x36.00(H)x13.50(T)mm

Viewing Area

64.50x14.00mm

Active Area

59.46x5.96mm

Character Size

3.07x5.96mm

IC Package

COB

Display Type

FSTN /STN. Gray/Yellow-Green/Blue

Viewing Direction

6:00/12:00

Power Supply(Typ)

3.3V/5.0V

Operating Temperature

-20℃~70℃

Storage Temperature

-30℃~80℃





Display Format Model No. Outline Dimension Viewing Area Active Area IC Interface Datasheet Download
16 x 1 SDCB1601-01 80.00(W)x36.00(H)x13.50(T)mm 64.50x14.00mm 59.46x5.96mm ST7066U AIP31066 HD44780 6800 4-bit / 8-bit Parallel
16 x 1 SDCB1601-02 122.00(W)x33.00(H)x13.00(T)mm 99.00x13.00mm 94.84x9.96mm ST7066U AIP31066 HD44780 6800 4-bit / 8-bit Parallel
